Internal Corner

The Internal Corner Trim has been designed to provide the

perfect fi nish in instances where tiles or any other surface

fi nish join at a 90° angle horizontally or vertically. The trims

primary purpose is to create an area which is easy to clean

however it also provides a solution to cracking grout within

internal corners.

It is often diffi cult to grout an internal corner perfectly. The

Internal Corner Trim can be used as an alternative allowing

tiles to be installed underneath the fi nishing lip – hiding

unsightly cuts. The installation is then sealed with a silicone.

The Internal Corner is available in two sizes as listed below.

Internal Corner

Internal Corner – Available in 3m lengths

B.A.T. Code: A (mm) B (mm) C (mm) D (mm) E (mm)

BIC-8-3- 36.00 20.00 2.00 8.00 1.20

BIC-10-3- 40.00 20.00 2.00 10.00 1.20

Available in the following Anodised Colours:

BG – Bright Gold BS – Bright Silver MS – Matt Silver.

Other colours available on request.

Available in the Following Powdercoated Colours:

AI – Almond Ivory AP – APO Grey BK – Gloss Black WH – Pearl White.

Other colours available on request.
